Description
Motorola IPMC761
Technical Specifications:
- Brand: Motorola
- Model: IPMC761
- Product Type: IPMC Module
- Standard: PICMG 3.0 / IPMI 2.0
Functional Features:
- Power and Thermal Management: Dynamically controls the power-up sequence and fan speed of blade servers.
- Out-of-Band Management: Allows administrators to remotely monitor hardware status even when the network is disconnected or the system is down.
- Sensor Polling: Real-time collection of critical sensor data including temperature, voltage, and current.
Application Scenarios:
Telecom-grade ATCA communication platforms and large data center server chassis.
Performance Parameters:
Features microsecond-level power protection response speed and supports high-speed I2C bus communication.
Material Composition:
High-Density Interconnect (HDI) PCB and precision connectors.
Structural Characteristics:
Slender ATCA IPMC standard dimensions with a 32-pin connector.
Working Principle:
Communicates with the Shelf Manager (ShMM) and node boards via the I2C bus to execute FRU (Field Replaceable Unit) information reading and power enable control.
Installation Requirements:
Must be inserted into the designated IPMC slot in the ATCA chassis, ensuring the retaining screw is tightened.
Precautions for Use:
IPMC firmware upgrades must be handled with extreme caution; incorrect firmware can cause the entire chassis power management to fail.
