Description
Motorola MVME 2304-0141
Technical Specifications
- Processor: MPC603 RISC architecture.
- Memory/Storage: 0141 exclusive capacity configuration.
- Interfaces: Dual PMC slots, 10/100 Ethernet, debug serial port.
Functional Features
- Highly integrated computing and I/O expansion capabilities.
- Comprehensive Power-On Self-Test (POST) and diagnostic functions.
- Supports multiple real-time operating systems.
Application Scenarios
Widely used in mission-critical systems, power monitoring, traffic control, and complex embedded computing platforms.
Performance Parameters
- Stable VME bus timing and data transfer rates.
- Excellent EMI and ESD immunity.
Material Composition
High-reliability industrial-grade electronic components on a flame-retardant PCB substrate.
Structural Characteristics
Standard 6U VME size with clear model and configuration identifiers on the front panel.
Working Principle
After initialization, the processor loads firmware, manages local devices via the PCI bridge, and responds to read/write requests on the VME bus through the Universe ASIC.
Installation Requirements
- Verify the hardware configuration list before installation.
- Ensure unobstructed chassis cooling airflow.
Usage Precautions
- Hot-plugging the module is strictly prohibited.
- Regularly clean internal chassis dust to prevent overheating.
