Motorola MVME117A

Motorola MVME117A

Product Introduction
The MVME117A is an enhanced version of the MVME117 series, featuring optimized electrical and mechanical designs over the original MC68030 architecture. It improves overall module reliability and anti-interference capabilities, representing a mature iteration of the classic 68k VME platform.

Request Quote
Category:

Description

Motorola MVME117A

Technical Specifications

  • Microprocessor: MC68030.
  • I/O Interfaces: Serial, SCSI, Ethernet (optional).
  • Bus: VMEbus System Controller/Slave.

Functional Features

  • Enhanced power management and protection circuits.
  • Optimized signal integrity design.
  • Compatible with standard MVME712 transition modules.

Application Scenarios
Used in mission-critical systems demanding extreme stability, such as power monitoring, traffic control, and aerospace testing.

Performance Parameters

  • Exhibits excellent Electromagnetic Compatibility (EMC) performance.
  • Supports wide operating temperature ranges.

Material Composition
High-quality flame-retardant PCB materials with gold-plated connector contacts.

Structural Characteristics
Standard 6U VME size, optionally featuring reset and abort switches on the front panel.

Working Principle
The MC68030 processor collaborates with peripheral chips to communicate with other system modules via the VME bus, executing real-time control algorithms.

Installation Requirements

  • Ensure backplane P1/P2 connectors are free from physical damage.
  • Use a torque screwdriver to tighten front-panel mounting screws.

Usage Precautions

  • Periodically inspect connector pins for cleanliness.
  • Adhere strictly to ESD protection protocols during handling.
