Description
Motorola MVME162-202
Technical Specifications:
- Brand: Motorola
- Model: MVME162-202
- Processor: MC68LC040 or MC68040 (25 MHz)
- Flash Memory: 1MB Flash for onboard monitor/debugger or user firmware
Functional Features:
- Processor Flexibility: Available with or without FPU (MC68040 vs. MC68LC040).
- Space-Efficient Expansion: Up to four single-width or two double-width IndustryPack modules in a single VME slot.
- Remote Management: Supports remote RESET/ABORT/STATUS control for unattended sites.
Application Scenarios:
Power system automation, metallurgical/chemical process control, and medical device core control.
Performance Parameters:
Exceptional anti-interference capability and continuous operational stability with extremely high MTBF.
Material Composition:
Industrial-grade PCB designed for forced-air cooling architectures.
Structural Characteristics:
Optional SCSI and Ethernet interfaces for connecting external storage and host networks.
Working Principle:
Boots via the 162Bug firmware, loads VxWorks or pSOS, and manages hardware resources to execute complex control logic.
Installation Requirements:
Pair with MVME712 transition modules to provide standard DB-type I/O interfaces.
Precautions for Use:
When using third-party memory expansions, verify timing compatibility or adjust BIOS wait-state parameters.
