Description
Motorola MVME162-253
Technical Specifications
- Product Series: MVME162 Series Single-Board Computer.
- Processor: Motorola 68040 or similar architecture microprocessor.
- Memory: Onboard DRAM (e.g., 4MB or higher configuration).
- Bus: Standard VMEbus interface.
Functional Features
- High Reliability: Field-proven over long periods with an extremely low failure rate.
- Rich Interfaces: Provides serial, parallel, and various expansion interfaces.
- Real-Time Performance: Optimized interrupt response mechanisms to meet hard real-time control requirements.
Application Scenarios
Widely applied in industrial automation, process control, test and measurement, and legacy system maintenance.
Performance Parameters
- Processing Performance: Stable 32-bit computing capability.
- Memory Performance: Reliable DRAM configuration.
Material Composition
Industrial-grade multi-layer PCB populated with 68040 CPU, DRAM, and power management chips.
Structural Characteristics
Standard 6U VME board size with front-panel debug serial ports and status LEDs.
Working Principle
Executes the boot program in ROM upon power-up to load the operating system. Communicates with external devices via the VME bus and executes real-time control tasks.
Installation Requirements
- Verify that the backplane slot supports the required
