Description
Motorola MVME162-408
Technical Specifications
- Processor: High-speed MC68040.
- Onboard Peripherals: Integrates Ethernet, SCSI, and multi-port serial interfaces.
- Memory: High-capacity DRAM and Flash.
Functional Features
- High Integration: Single card achieves control, communication, and storage functions.
- High-Speed Networking: Onboard 10Base-T Ethernet supporting DMA transfers.
- Mass Storage: Supports SCSI interface for connecting hard drives or tape drives.
Application Scenarios
Data recording systems, large industrial gateways, and complex test stands.
Performance Parameters
- Network Speed: 10 Mbps Ethernet.
- Storage Interface: SCSI-2 supporting high-speed data transfer.
Material Composition
Industrial-grade PCB integrating high-density ASIC chips.
Structural Characteristics
Front panel provides RJ-45 network port, DB-25 SCSI port, and serial ports.
Working Principle
Processes TCP/IP protocol stacks via the onboard network controller, manages external storage devices using the SCSI controller, and achieves local data recording and remote uploading.
Installation Requirements
- Observe cable length and termination matching when connecting SCSI devices.
- Ensure network cables meet 10Base-T standards.
Usage Precautions
- Avoid hot-plugging SCSI devices (unless hot-plug supported).
- Regularly check the stability of network connections.
