Description
Motorola MVME162-430
Technical Specifications
- Processor: MC68040 or MC68LC040.
- Storage: 1MB Flash, 512KB SRAM (battery-backed).
- Communication: Onboard Ethernet, SCSI, and multi-port serial.
- Expansion: Supports IndustryPack modules.
Functional Features
- High Integration: Single card achieves control, communication, and storage functions.
- Non-Volatile Resources: Onboard NVRAM and RTC ensure system configuration and timestamps are retained after power loss.
- Long Lifecycle: As a mature product, it offers extensive spare parts availability and technical support.
- Software Ecosystem: Fully supports classic real-time operating systems like VxWorks, pSOS, and OS-9.
Application Scenarios
Suitable for semiconductor manufacturing equipment, railway transit subsystems, and Automated Test Equipment (ATE).
Performance Parameters
- Network Speed: 10Base-T Ethernet.
- Storage Interface: SCSI-2 supporting high-speed data transfer.
Material Composition
Industrial-grade electronic components, strictly screened and burn-in tested.
Structural Characteristics
6U Eurocard format with clear silkscreen markings and RJ-45 interfaces on the front panel.
Working Principle
Processes TCP/IP protocol stacks via the onboard network controller, manages external storage devices using the SCSI controller, and achieves local data recording and remote uploading.
Installation Requirements
- Ensure the backplane provides a stable +5V power supply.
- Observe cable length and termination matching when connecting SCSI devices.
Usage Precautions
- Avoid hot-plugging SCSI devices.
- Regularly check the stability of network connections.
