Description
Motorola MVME162PA-344E
Technical Specifications:
- Brand: Motorola
- Model: MVME162PA-344E
- Processor: Motorola 68040 or 68060 series microprocessor
- Memory: Onboard DRAM and battery-backed SRAM/NVRAM
Functional Features:
- High Reliability: Features strong anti-interference capabilities and is fully compliant with standard VMEbus specifications.
- Broad Compatibility: Easily integrated into existing systems, supporting mature real-time operating systems.
Application Scenarios:
Widely used in legacy industrial control system upgrades, traffic control, medical equipment, and test equipment.
Performance Parameters:
32-bit data processing capability with operating frequencies reaching tens to hundreds of megahertz, providing deterministic real-time control performance.
Material Composition:
Industrial-grade components that have undergone rigorous screening and burn-in testing.
Structural Characteristics:
Standard 6U VME size equipped with P1/P2/VME64 extension connectors.
Working Principle:
Executes the Motorola 68k instruction set and communicates with memory-mapped I/O devices via the VME bus.
Installation Requirements:
Onboard jumpers or DIP switches must be correctly configured to set the base address and interrupt levels.
Usage Precautions:
Monitor the lifespan of the onboard battery (used for CMOS and SRAM retention) and replace it promptly to prevent data loss.
