Motorola MVME167-002BE
Technical Specifications
- Processor: PowerPC 603e RISC microprocessor.
- Cache: 16KB L1 instruction and data caches.
- Memory: Supports ECC DRAM via RAM167 mezzanine modules.
- I/O: Integrated Ethernet, SCSI, and serial controllers.
Functional Features
- RISC Architecture: Superscalar execution with dynamic branch prediction.
- Low Power: Reduced power consumption compared to equivalent 680×0 designs.
- Memory Expansion: Flexible mezzanine-based memory expansion.
- VME Interface: Full VME64 compliance with 2eSST support.
Application Scenarios
Ideal for telecommunications, industrial automation, and test and measurement.
Performance Parameters
- Clock Speed: High-frequency PowerPC 603e operation.
- Bus Bandwidth: Optimized for VME64 block transfers.
Material Composition
High-Tg industrial PCB with gold-plated VME connectors and precision SMT assembly.
Structural Characteristics
6U VME single-board computer with front panel I/O and status indicators.
Working Principle
The PowerPC 603e manages local resources via the PCI local bus, bridging to the VME backplane via a VMEbus interface controller.
Installation Requirements
Insert into a 6U VME chassis. Ensure proper grounding of the chassis.
Usage Precautions
Always use ESD protection. Do not force the board into the backplane slot.
