Description
Motorola MVME167-DEBUG
Technical Specifications
- Function: Hardware debugging and diagnostics.
- Interfaces: Extended test points and debug headers.
- Compatibility: Designed for MVME167 series SBCs.
- Features: Enhanced firmware monitor and trace capabilities.
Functional Features
- Deep Diagnostics: Access to internal bus signals and processor states.
- Firmware Debug: Advanced monitor commands for memory and I/O testing.
- Trace Support: Hardware trace buffer for instruction flow analysis.
- Test Points: Exposed signals for oscilloscope and logic analyzer connection.
Application Scenarios
Essential for system integrators, firmware developers, and maintenance engineers working with MVME167 platforms.
Performance Parameters
- Debug Bandwidth: High-speed trace and test point access.
- Firmware: Enhanced diagnostic ROM.
Material Composition
Industrial PCB with robust connectors and test point headers.
Structural Characteristics
6U VME form factor with extensive front panel debug connectors and indicators.
Working Principle
Intercepts and monitors bus transactions, providing real-time visibility into system operation for debugging and validation.
Installation Requirements
Install in a VME chassis alongside the target MVME167 SBC. Connect debug cables as required.
Usage Precautions
Use only for debugging and development. Do not deploy in production systems unless specifically validated.
