Motorola MVME172P-644L
Technical Specifications
- Processor: 64 MHz 68LC060 microprocessor.
- Memory: 16 MB SDRAM.
- Serial Interfaces: 2x EIA-232-D ports.
- DMA Channels: 4 Direct Memory Access channels to reduce CPU overhead.
Functional Features
- Efficient DMA: Four DMA channels support high-speed data transfers without CPU intervention.
- Cost-Effectiveness: Delivers powerful functionality while maintaining a highly competitive cost.
- Broad Support: Extensive documentation and development tools accelerate time-to-market.
Application Scenarios
General industrial automation, test and measurement equipment, medical devices, and traffic control systems.
Performance Parameters
- Clock Speed: 64 MHz frequency offers higher processing performance than 60 MHz variants.
- Timers: Multiple 32-bit timers for precise time control and event triggering.
- Reliability: High MTBF suitable for 24/7 continuous operation.
Material Composition
High-quality FR-4 PCB material with lead-free soldering processes, compliant with environmental standards.
Structural Characteristics
Standard 6U VME size with a compact layout that optimizes airflow cooling paths.
Working Principle
Leverages the powerful instruction set of the 68LC060 processor to efficiently execute multi-tasking real-time operating systems and manage I/O and communications.
Installation Requirements
Verify VME chassis power capacity meets requirements. Correctly set address and interrupt jumpers on the board.
Usage Precautions
Check all jumper settings before initial power-up. Avoid storage in humid environments and follow manual guidelines for firmware upgrades.
