Description
Motorola MVME172PA-642SE
Technical Specifications
- Processor: 60 MHz MC68060.
- Core Chip: Second-Generation Petra ASIC.
- Network: 10/100Mbps Ethernet.
- Memory: 16 MB SDRAM.
Functional Features
- Enhanced Networking: Optimized ASIC improves Ethernet DMA efficiency.
- High Reliability: Second-Gen Petra reduces external component count, increasing system stability.
- Seamless Upgrade: Provides a performance enhancement path for existing 642SE users.
Application Scenarios
Industrial control requiring highly reliable network communication, distributed I/O systems, and modernization of existing infrastructure.
Performance Parameters
- Network Throughput: Optimized DMA controller improves network data transport efficiency.
- System Response: Faster memory access results in lower system latency.
- Long-Term Availability: Second-generation products typically offer extended supply cycles.
Material Composition
Industrial-grade components with mature ASIC processes resulting in lower power consumption and heat generation.
Structural Characteristics
Mechanically compatible with the MVME172PA-642SE with identical front panel interface layouts.
Working Principle
Leverages the second-gen Petra ASIC’s efficient memory and bus controllers to accelerate network data processing and control logic execution.
Installation Requirements
Direct replacement for legacy boards; verify network configurations post-installation.
Usage Precautions
Run a full system diagnostic after upgrading. Monitor network performance to validate the improvement.
