Description
Motorola MVME187-034A
Technical Specifications
- Processor: MC88100 RISC processor.
- Memory: Standard capacity ECC DRAM.
- Interfaces: Ethernet, SCSI, and multiple EIA-232-D serial ports.
Functional Features
- Universal Compatibility: Fully compliant with VMEbus IEEE 1014 standards.
- Robust Firmware: 187Bug provides a stable foundation for booting various real-time operating systems.
- Expandability: Supports VMEbus expansion for additional I/O modules.
Application Scenarios
PLC backplanes, motion control, environmental monitoring, and security surveillance systems.
Performance Parameters
- Throughput: Sustained VMEbus block transfer rates for efficient data logging.
- Reliability: 7×24 hour continuous operation capability.
Material Composition
Automated surface-mount assembly with rigorous AOI (Automated Optical Inspection) and functional testing.
Structural Characteristics
Compact 6U VME layout optimized for high-density chassis configurations.
Working Principle
Acts as the central compute node, coordinating data flow between VME I/O modules and external Ethernet networks.
Installation Requirements
Follow the manufacturer’s specified power-on sequence to ensure proper initialization of the VME bus arbiter.
Usage Precautions
Avoid exposing the board to conductive dust or metallic debris inside the chassis.
