Description
Motorola MVME2400
Technical Specifications:
- Brand: Motorola
- Model: MVME2400 Series
- Architecture: PowerPlus II
- Bus Interface: VMEbus / PCI Local Bus
Functional Features:
- High Flexibility: Provides an excellent base platform for rapid and easy customization for specific industry applications.
- PMC Expansion: Supports functional expansion via PCI Mezzanine Cards (PMC).
Application Scenarios:
Industrial automation, data acquisition and processing, communication equipment, and medical devices.
Performance Parameters:
High-performance PowerPC processor paired with large-capacity ECC SDRAM memory.
Material Composition:
Industrial-grade standard materials ensuring long-term reliability.
Structural Characteristics:
Single-slot VME module supporting front-panel I/O or backplane I/O.
Working Principle:
Utilizes a PCI-to-VME bridge chip to achieve high-efficiency communication between the processor and the VME bus.
Installation Requirements:
Confirm that the chassis supports PMC expansion space if required by the application.
Usage Precautions:
When configuring PMC cards, carefully manage resource allocation to avoid interrupt or memory conflicts.
