Description
Motorola MVME2603-1141C
Technical Specifications
- Core Processor: PowerPC 603 32-bit microprocessor.
- Bus Interface: VMEbus-to-local-bus interface supporting A24/A32, D8/D16/D32/block transfers.
- Peripheral Support: Supports keyboard, mouse, floppy disk/LED interfaces, and PCI expansion.
Functional Features
- Comprehensive Diagnostics: Six front-panel status LEDs (CHS, BFL, CPU, FUS, SYS, PCI) for rapid troubleshooting.
- Flexible Configuration: On-board reset and abort switches for convenient hardware debugging.
- Real-Time Clock: Integrated NVRAM/RTC with battery backup to ensure continuous time base.
Application Scenarios
Ideal for industrial control consoles, testing equipment, and embedded servers requiring high reliability and rich human-machine interaction interfaces.
Performance Parameters
- Operating Temperature: 0°C to 55°C with forced-air cooling.
- Storage Temperature: -40°C to +85°C.
Material Composition
Industrial-grade components with PCB strictly optimized for signal integrity and thermal management.
Structural Characteristics
Standard VME 6U dimensions featuring status indicator lights and debug interfaces on the front panel.
Operating Principle
Manages PCI devices and VME interfaces via the local bus, utilizing interrupt handlers to respond to external events for highly efficient real-time control.
Installation Requirements
Verify that transition module jumper settings match the base board configuration before installation. Ensure proper chassis grounding.
Usage Precautions
Regularly monitor front-panel LED status. If the BFL (Bus Fault) or FUS (Fuse) LED illuminates, investigate and resolve the hardware fault immediately.
