Description
Motorola MVME2604-1351
Technical Specifications
- Core Processor: 333 MHz MPC604 32-bit microprocessor.
- Bus Interface: A32/D32 VMEbus master/slave interface supporting multi-mode interrupt handling.
- Peripheral Controllers: On-board SCSI, Ethernet, and serial/parallel interface controllers.
- Firmware: Built-in PPCBug debug monitor firmware providing rich debugging and boot commands.
Functional Features
- High Integration: Highly integrated on-board resources and peripheral controllers free up VME bus slots.
- Fast Response: Supports multi-mode interrupt handling to ensure rapid response to real-time events.
- Easy Development: Provides rich development tools, drivers, and on-board debuggers.
Application Scenarios
Suitable for automated test equipment, large PLC system main controllers, robot controllers, medical imaging equipment, and monitors.
Performance Parameters
- Power Requirements: +5V DC, typical power consumption between 5-10W.
- Data Throughput: Supports high-speed data transfer compliant with VME64 standards.
Material Composition
Constructed with high-reliability industrial-grade chips, subjected to strict environmental stress screening.
Structural Characteristics
Standard VME card form factor. Features status indicators on the front panel and interfaces with the chassis backplane via P1/P2 connectors at the rear.
Operating Principle
Acts as an intelligent node connected to the VME system, responding to external events via interrupt mechanisms. Utilizes on-board DMA controllers to independently handle SCSI or Ethernet data transfers, reducing CPU burden.
Installation Requirements
Insert vertically into the VME chassis, applying even pressure to prevent bending of connector pins. Ensure the chassis is properly grounded.
Usage Precautions
Avoid use in environments exceeding specified humidity levels to prevent short circuits caused by condensation. In case of system crashes, the hardware watchdog timer can automatically reset the system.
