Product Brief The MVME2604-2141A is a VME64 processor module from Motorola’s MVME2600 series, featuring a 200 MHz MPC604e PowerPC processor with 64MB ECC DRAM. This model uses the MVME712 I/O transition module and is equipped with a VME Scanbe front panel. The “A” suffix indicates a product revision with enhanced reliability. It represents a mid-range configuration within the 200 MHz processor tier, offering substantial memory capacity for demanding embedded applications.

Request Quote
Category:

Description

Motorola MVME2604-2141A

Technical Specifications

  • Processor: 200 MHz Motorola PowerPC 604e 32-bit microprocessor
  • L2 Cache: 256KB
  • Memory: 64MB ECC DRAM
  • Flash Memory: 9MB
  • VMEbus Interface: Full VME64 bus interface
  • I/O Transition Module: MVME712
  • Front Panel: VME Scanbe front panel with handles

Key Features

  • PowerPlus Architecture with Motorola proprietary ASICs
  • 256KB L2 cache for improved processor performance
  • 64MB ECC DRAM for data integrity
  • 9MB on-board Flash for firmware storage
  • MVME712 I/O transition module support
  • VME Scanbe front panel for traditional VME installations
  • High-bandwidth VME64 data transfers

Application Scenarios Industrial automation control, telecommunications switching equipment, military C4ISR systems, aerospace electronics, medical imaging equipment, test and measurement systems

Performance Parameters

  • Processor Clock: 200 MHz
  • L2 Cache: 256KB
  • Memory: 64MB ECC DRAM
  • Flash: 9MB
  • Bus Standard: VME64
  • Front Panel: VME Scanbe

Material Composition Industrial-grade multi-layer PCB with high-reliability components. Connectors feature gold-plating for long-term durability in harsh environments.

Structural Characteristics Standard 6U VME form factor (233mm x 160mm). VME Scanbe front panel with handles for easy installation and removal. P2 connector interfaces with MVME712 transition module.

Working Principle Based on PowerPC 604e superscalar architecture. Motorola proprietary ASICs optimize processor, cache, and I/O performance. The VME64 interface provides high-bandwidth data transfer between the local bus and VME backplane.

Installation Requirements Standard VME64 chassis with proper cooling. MVME712 transition module requires intact P2 backplane connector. Ensure adequate power delivery for 64MB memory configuration.

Usage Notes Verify compatibility with MVME712 transition module cabling. Monitor ECC memory status regularly. Ensure chassis cooling is sufficient for sustained operation at 200 MHz.
