Description
Motorola MVME2604-4341
Technical Specifications
- Core Components: 333 MHz MPC604 PowerPC processor.
- Expansion Interfaces: Supports VXS, PCI, and other expansion interfaces for adding various expansion cards.
- Operating Systems: Supports VME Basic, Linux, Windows, and various other operating systems.
- Peripheral Interfaces: Includes serial, parallel, and SCSI bus interfaces.
Functional Features
- High Scalability: Rich expansion interfaces allow users to flexibly add CPU cards, I/O cards, or memory according to their needs.
- Seamless Integration: Excellent compatibility allows seamless integration with other VME boards and devices.
- Strong Flexibility: Supports multiple operating systems to meet diverse user development and deployment requirements.
Application Scenarios
Suitable for communication equipment, healthcare medical devices, aerospace, and complex industrial control systems requiring high scalability.
Performance Parameters
- Bus Bandwidth: Provides high-bandwidth bus support.
- Processor Clock: 333 MHz.
Material Composition
Selected high-quality electronic components ensuring long lifespan and high reliability.
Structural Characteristics
Modular design with compact PCB layout, facilitating maximum functional configuration within limited chassis space.
Operating Principle
Interacts with the system via the VME bus. Utilizing the on-board high-performance processor and expansion interfaces, it achieves rapid data acquisition and complex logical control of external devices.
Installation Requirements
When installing expansion cards, ensure sufficient power capacity and verify that the bus load is within allowable limits.
Usage Precautions
Always cut system power before adding or removing expansion cards (unless explicitly supporting hot-swap). Regularly clean dust inside the chassis to maintain good heat dissipation.
