Description
Motorola MVME2604-712I-0
Technical Specifications
- Microprocessor: PowerPC MPC604 at 400 MHz.
- Memory: 0 to 512MB ECC DRAM, configurable based on application requirements.
- Flash Memory: 9MB of onboard Flash for reliable firmware storage.
- Power Consumption: +5Vdc at 6A typical / 8A maximum; +12Vdc at 250mA typical / 1A maximum.
Functional Features
- Industrial Hardening: Enhanced component selection for extended operating temperature ranges.
- Comprehensive Diagnostics: Six front-panel LEDs for real-time status monitoring of CPU, bus, and peripheral states.
- Flexible Boot Options: Supports boot from Flash, Ethernet, or SCSI devices.
Application Scenarios
- Oil & Gas: Offshore platform control systems and pipeline monitoring.
- Power Generation: Turbine control and substation automation.
- Transportation: Railway signaling and traffic management systems.
Performance Parameters
- Operating Temperature: Extended industrial range with forced-air cooling.
- Storage Temperature: -40°C to +85°C.
- Vibration Resistance: Industrial-grade shock and vibration tolerance.
Material Composition
Industrial-grade PCB with conformal coating options, high-reliability capacitors, and sealed NVRAM module.
Structural Characteristics
- Form Factor: Double-high 6U VME with MVME712 transition module.
- Dimensions: Standard VME 6U mechanical footprint with extended depth for transition module.
Working Principle
The 400 MHz MPC604 processor manages system resources through the Falcon chipset, utilizing DMA for high-speed data transfers between ECC memory, PCI devices, and the VMEbus.
Installation Requirements
- Install in a ventilated 6U VME chassis with forced-air cooling.
- Ensure proper torque on captive screws to maintain EMI shielding and mechanical stability.
Usage Precautions
- Verify power supply can deliver peak current during processor boot.
- Follow ESD protocols strictly during installation and maintenance.
- Monitor front-panel LEDs for fault indication during operation.
