Description
Motorola MVME2700-1421
Technical Specifications
- Processor: 366 MHz MPC750-class 32-bit microprocessor
- L1 Cache: 32KB instruction / 32KB data cache
- L2 Cache: 1MB backside cache
- Memory: 16MB ECC DRAM
- Flash Memory: 9MB on-board Flash
- VMEbus Interface: VME64 master/slave
- I/O Transition Module: MVME761
- Front Panel: IEEE 1101 compatible with injector/ejector handles
- Serial Ports: Two or three async, one or two sync/async
- Ethernet: 10BaseT/100BaseTX with 32-bit PCI DMA
- SCSI: 8-bit or 16-bit Fast SCSI-2
- NVRAM: 8KB with battery-backed TOD clock
- Timers: Four 32-bit plus watchdog
Key Features
- 366 MHz MPC750 for highest processing speed
- 1MB backside L2 cache
- 16MB ECC DRAM
- 9MB Flash memory
- MVME761 I/O transition module
- IEEE 1101 front panel
- On-board PPCBug debug monitor
- Self-test diagnostic capabilities
Application Scenarios High-performance industrial control, military signal processing, aerospace computing, telecommunications core processing, radar systems, scientific instrumentation
Performance Parameters
- Processor Clock: 366 MHz
- L1 Cache: 32KB + 32KB
- L2 Cache: 1MB
- Memory: 16MB ECC DRAM
- Flash: 9MB
- Ethernet: 10/100Base-TX
- SCSI: Fast SCSI-2
- NVRAM: 8KB with TOD
Material Composition High-performance industrial-grade materials. Components selected for reliable 366 MHz operation. Enhanced gold-plated connectors. Robust IEEE 1101 front panel construction.
Structural Characteristics 6U VME standard dimensions. IEEE 1101 front panel with handles. LED status indicators. P2 connector for MVME761. DRAM mezzanine connector for memory upgrades.
