Description
Motorola MVME297-12828MB
Technical Specifications
- Part Number: MVME297-12828MB
- Manufacturer: Motorola
- Product Type: VME Memory Board
- Memory Capacity: 128MB
- Compatible System: MVME197 series
Key Features
- 128MB large-capacity memory expansion
- Specifically designed for MVME197 series processor boards
- VME bus interface, fully compatible with Motorola VME systems
- Industrial-grade reliability design for harsh working environments
- High-speed memory access support
- Variant configuration of the standard MVME297-128
Application Scenarios Large industrial control system memory expansion, military electronic equipment memory enhancement, telecommunications infrastructure memory expansion, data acquisition system memory upgrade, scientific computing equipment memory extension, embedded server memory upgrade
Performance Parameters
- Memory Capacity: 128MB
- Bus Type: VME
- Compatibility: MVME197 series
Material Composition Industrial-grade multi-layer printed circuit board with high-quality industrial-grade DRAM memory chips, rigorously screened and tested. Connectors feature high-reliability gold-plating for long-term stable operation in demanding environments.
Structural Characteristics Standard VME board size, connecting to the backplane through VME connectors. Compact module design ensures proper installation within standard VME chassis.
Working Principle Connects to the main processor board through the VME bus interface, with the main board memory controller managing the expanded memory uniformly. The expanded memory and on-board memory together constitute the system memory space, with the processor accessing all memory resources through a unified high-speed bus.
Installation Requirements Requires compatible Motorola MVME197 series main processor boards, ensuring the main board supports 128MB memory expansion. Follow standard anti-static operating procedures during installation, ensuring connectors are fully inserted.
Usage Notes Confirm main board BIOS or firmware support for 128MB memory expansion before installation. Pay attention to anti-static protection during installation to avoid damaging sensitive memory chips. Regularly check module fixation status to prevent loosening due to transportation or vibration. Monitor system temperature to ensure proper memory board cooling.
