Description
Motorola MVME3604-5131B
Technical Specifications
- Full Model: MVME3604-5131B.
- Revision Level: Revision B hardware baseline.
- System Bus: VMEbus parallel data transfer bus.
Functional Features
- Version Optimization: Revision B improves electrical characteristics and firmware compatibility.
- Flexible Configuration: Allows system parameter adjustments via software or hardware jumpers.
- High Stability: Field-proven over long periods with an extremely low failure rate.
Application Scenarios
Serves as an upgrade spare for existing VME systems or the core controller for newly built high-reliability industrial control systems.
Performance Parameters
- Bus Speed: Supports VME64 high-speed transfer modes.
- Memory Capacity: High-capacity RAM designated by the 5131 configuration.
Material Composition
High-quality electronic components with PCB conformal coating for moisture and dust resistance.
Structural Characteristics
Standard 6U VME board size equipped with auxiliary power interfaces and debug serial ports.
Working Principle
After power-on reset, Revision B firmware automatically performs hardware self-tests. Exchanges data with system memory or other modules via the VME data bus while executing pre-installed control programs.
Installation Requirements
- Inspect P1/J1 and P2/J2 backplane connectors for physical damage before installation.
- Keep the board perpendicular during insertion and apply even pressure.
Usage Precautions
- Evaluate whether system software requires updates when replacing non-Revision B modules.
- Never touch integrated circuit pins on the PCB directly with bare hands.
