Motorola MVME5101-0131
Technical Specifications:
- Brand: Motorola
- Model: MVME5101-0131
- Product Type: VME SBC
- Bus Standard: VME64
Functional Features:
- Rugged Embedded Architecture: Fanless, no moving parts design, adapting to extreme harsh environments.
- Broad OS Support: Natively supports various real-time and general-purpose operating systems including VxWorks, OS-9, Solaris, and Linux.
- Large Capacity Memory: Onboard large-capacity SDRAM supporting ECC error correction.
Application Scenarios:
Aerospace, defense/military, nuclear energy control, rail transit, and large-scale medical equipment.
Performance Parameters:
Provides stable MHz-level processing clock frequencies with extremely low Mean Time Between Failures (MTBF).
Material Composition:
Military/industrial-grade components, heavy-copper PCB to withstand high currents and high temperatures.
Structural Characteristics:
Standard 6U VME dimensions, equipped with P1/P2 high-density DIN 41612 connectors and a robust metal heat dissipation frame.
Working Principle:
Obtains power and interrupts via the VME backplane; the onboard Boot ROM boots the operating system and provides flexible I/O expansion capabilities through PMC/XMC expansion slots.
Installation Requirements:
The VME address jumpers and Interrupt Request (IRQ) jumpers on the board must be set correctly to prevent bus conflicts.
Precautions for Use:
VME connector pins are dense and fragile; insertion and removal must be kept perfectly horizontal, and violent operations are strictly prohibited.
