Description
Motorola MVME51105E-2163
Technical Specifications
- Processor: PowerPC 603e running at 166 MHz.
- Memory: 32 MB DRAM.
- Communication: Dual 10/100Mbps Ethernet and dual serial ports.
- Storage: 4 MB Flash.
Functional Features
- Dual Network Redundancy: Supports redundant network configurations to improve system availability.
- High Performance: 166 MHz PowerPC paired with large memory handles complex tasks effortlessly.
- Industrial-Grade Design: Designed for 24/7 continuous operation with extremely high MTBF.
Application Scenarios
Distributed control systems, remote I/O stations, data acquisition gateways, and industrial applications requiring highly reliable network communication.
Performance Parameters
- Network Throughput: Dual Ethernet provides extremely high network bandwidth.
- Processing Power: 166 MHz main frequency meets multi-tasking concurrent demands.
- Data Integrity: Enhanced error detection mechanisms.
Material Composition
Industrial-grade components with PCB design fully considering high-speed signals and EMC requirements.
Structural Characteristics
Front panel integrates dual RJ-45 network ports with status LEDs for convenient field diagnostics.
Working Principle
Achieves high-speed data exchange via dual Ethernet interfaces, utilizing the efficient processing power of the PowerPC for real-time control.
Installation Requirements
Use qualified shielded network cables. Ensure proper network grounding to avoid ground loop interference.
Usage Precautions
Watch for IP address conflicts during network configuration. Avoid connecting outdoor network cables during thunderstorms.
