Description
Motorola MVME61006E-2173
Technical Specifications
- Core Architecture: 1.267 GHz MPC7457 PowerPC processor with MV64360 system controller.
- Memory Configuration: Customized ECC DDR DRAM capacity based on specific project requirements.
- Storage: 128 MB Flash memory, potentially partitioned or configured for specific boot sequences.
- Bus Interface: Standard 6U VME/VXS interface supporting 2eSST.
Functional Features
- Bespoke Configuration: Hardware and firmware customized at the factory to meet exact system integration needs.
- Enhanced Reliability: Maintains the stringent “6E” quality assurance and extended burn-in testing standards.
- Seamless Integration: Designed to act as a direct drop-in replacement or upgrade within existing VME ecosystems.
Application Scenarios
Deployed in highly specialized defense projects, proprietary industrial OEM equipment, dedicated medical imaging systems, and critical infrastructure control systems requiring long-term supply stability.
Performance Parameters
- VME Protocol: Full support for 2eSST VME protocol, delivering up to 320 MB/s cross-backplane bandwidth.
- Cache Performance: 2 MB DDR SRAM L3 cache operating at 211 MHz to minimize memory latency.
- I/O Expansion: Dual PMC/PMC-X slots supporting up to 100 MHz PCI-X speeds.
Material Composition
Utilizes premium industrial-grade electronic components selected for long lifecycle and high reliability. The PCB is manufactured with specialized surface finishes to ensure long-term solder joint integrity and resistance to environmental degradation.
Structural Characteristics
- Standard Form Factor: Fully compliant with standard 6U VME mechanical dimensions (160 mm x 233 mm) for universal chassis compatibility.
- Custom Identifiers: Features unique silkscreen markings, part numbers, and barcode labels for precise inventory and maintenance tracking.
- Optimized Layout: Component placement may be adjusted to accommodate specific thermal or mechanical constraints of the target system.
