Description
Motorola MVME7100-0173-2GF
Technical Specifications
- Processor: 1.3 GHz MPC8641D dual-core PowerPC e600.
- Memory: 2 GB DDR2 ECC.
- Storage: 8 GB NAND Flash (extended), 128 MB NOR Flash.
- Network: Quad Gigabit Ethernet.
Functional Features
- Extended Storage: Large NAND capacity for data logging and applications.
- IEEE Standard: Broad mechanical and electrical compatibility.
- High Performance: 1.3 GHz dual-core processing with 2 GB RAM.
Application Scenarios
Edge data analytics, autonomous systems, and applications requiring local data persistence.
Performance Parameters
- Power: Typical 45W, Maximum 60W @ +5V.
- Storage Interface: High-speed NAND with wear-leveling support.
Material Composition
Industrial-grade components with extended endurance flash and robust PCB design.
Structural Characteristics
- Form Factor: 6U VME IEEE standard.
- Storage Management: Hardware-assisted flash management.
- Thermal Design: Optimized for storage and processor cooling.
Working Principle
The system leverages the extended NAND flash for high-capacity local storage while maintaining real-time VME communication. The dual-core processor handles both storage management and real-time control tasks efficiently.
Installation Requirements
- Standard VME installation procedures.
- Ensure power supply supports flash write operations.
- Configure storage during system initialization.
Usage Precautions
- Implement proper file system management.
- Monitor flash wear levels.
- Avoid operating in high-humidity environments.
