Motorola MVME8100
Technical Specifications
- Processor: Freescale QorIQ P5020 dual-core e5500 Power Architecture.
- Memory: Up to 8 GB DDR3-1333 ECC.
- Storage: 8 GB eMMC NAND, 512 KB F-RAM.
- Network: Five Gigabit Ethernet controllers.
Functional Features
- High-Speed Interconnects: PCIe and SRIO fiber optic interfaces.
- Data Security: F-RAM for critical data and secure boot.
- Expansion: 2.5-inch SATA bay and dual PMC/XMC slots.
Application Scenarios
C4ISR systems, radar and sonar, semiconductor equipment, and flight test instrumentation.
Performance Parameters
- Processing: Dual-core e5500 with high floating-point performance.
- Bandwidth: High-speed PCIe and SRIO for data-intensive applications.
- Memory: Up to 8 GB DDR3 ECC for large datasets.
Material Composition
Military-grade components, ruggedized PCB, and extended temperature ratings. Supports conduction cooling for sealed enclosures.
Structural Characteristics
- Form Factor: 6U VME/VXS.
- Environmental: -40°C to +85°C operating range, 10G vibration, 40G shock.
- Cooling: Conduction or forced-air cooling options.
Working Principle
The dual-core P5020 processor manages high-speed data flow through DDR3 memory, PCIe, and SRIO interfaces. The VME/VXS bridge enables integration with legacy backplanes while supporting modern high-speed interconnects.
Installation Requirements
- Install in 6U VME/VXS chassis.
- Ensure proper thermal management (conduction or air).
- Configure VME address and interrupt settings.
Usage Precautions
- Ensure board is dry before powering on.
- Do not operate outside environmental specifications.
- Secure SATA drive if installed.
- Observe ESD precautions at all times.
