Description
Motorola VME162PA-252SE
Technical Specifications:
- Brand: Motorola
- Model: VME162PA-252SE
- Processor: 32 MHz MC68040 Enhanced 32-bit Microprocessor
- Memory: 16MB Configurable SDRAM
- ASIC: Integrated Petra Special-Purpose Integrated Circuit
Functional Features:
- Petra ASIC Optimization: Significantly enhances memory subsystem performance and overall integration.
- Flexible Memory Configuration: Supports customizing SDRAM size via onboard switches.
- IndustryPack Support: Provides four IndustryPack ports for extensive expansion capabilities.
Application Scenarios:
OEM embedded monitoring, large-scale automation equipment master controllers, and high-speed data acquisition systems.
Performance Parameters:
32 MHz clock frequency with support for the VMEbus D64 specification.
Material Composition:
Industrial-grade multi-layer PCB utilizing high-density surface-mount technology.
Structural Characteristics:
Standard 6U VME size featuring IndustryPack expansion slots.
Working Principle:
Utilizes the Petra ASIC for global control, coordinating high-speed data flow between the microprocessor and VME bus DMA.
Installation Requirements:
Before installation, correctly set the onboard memory configuration switches according to the actual installed memory capacity.
Precautions for Use:
Strict chassis cooling requirements must be met; forced-air cooling is mandatory.
