SEW DRL160MC4/FI/TF/EG7S/V

SEW DRL160MC4/FI/TF/EG7S/V

Product Introduction:
The DRL160MC4/FI/TF/EG7S/V is an asynchronous servo motor from SEW-EURODRIVE’s DRL series, designed for high-dynamic positioning and speed control applications. The “DRL” prefix identifies the asynchronous servo motor series. The “160” denotes the frame size (160 mm center height). The “MC” indicates the mounting position (MC position). The “4” specifies a 4-pole motor configuration with a rated speed of approximately 1500 rpm. The “/FI” designates the output configuration (flange/interface type). The “/TF” indicates integrated thermal protection via PTC thermistors. The “/EG7S” specifies an additional external encoder with sinusoidal output signals for precise speed and position feedback. The “/V” denotes a forced cooling fan for enhanced thermal performance under high-duty-cycle operation.

Request Quote
Category:

Description

SEW DRL160MC4/FI/TF/EG7S/V

Technical Specifications:

  • Brand: SEW-EURODRIVE
  • Series: DRL (Asynchronous Servo Motor)
  • Frame Size: 160 (center height 160 mm)
  • Mounting Position: MC
  • Poles: 4-pole
  • Supply Voltage: 3 × 380–500 VAC
  • Insulation Class: F (155°C)
  • Protection Class: IP54 / IP55
  • Operating Mode: S1 continuous duty
  • Thermal Protection: PTC thermistors (/TF)
  • Encoder: External sinusoidal encoder (/EG7S)
  • Cooling: Forced ventilation fan (/V)
  • Output Configuration: FI type flange/interface

Functional Features:

  • High Dynamic Overload Capability: Supports dynamic overload currents up to 350% of rated current for short durations, divided into two dynamic power packages
  • Four Speed Levels: Available at 1200, 1700, 2100, and 3000 rpm for flexible application matching
  • High-Resolution Sinusoidal Encoder: The /EG7S encoder provides precise speed and position feedback for closed-loop vector control
  • Integrated Thermal Protection: PTC thermistors (/TF) embedded in the winding provide reliable overtemperature protection
  • Forced Cooling: The /V fan ensures consistent thermal performance even at low speeds and high continuous loads
  • Modular Compatibility: Fully compatible with SEW’s DR series modular motor system, allowing combination with servo gearboxes, brakes, and other accessories
  • High External Inertia Handling: Specifically designed to reliably control high external moments of inertia relative to the motor shaft

Application Scenarios:

  • Gantry picking robots
  • Traveling axes in palletizing machines
  • Winding drives and cutting drums
  • Gantry lifting axes
  • Conveyor applications with precise speed control
  • Machine tool feed drives
  • Printing and packaging machinery
  • Automated storage and retrieval systems

Performance Parameters:

  • Torque Range: 5 Nm to 200 Nm (across the DRL series range)
  • Nominal Torque: Dependent on specific 160MC4 configuration
  • Dynamic Overload: Up to 3 to 4 times rated torque for short durations
  • Speed Levels: 1200 / 1700 / 2100 / 3000 rpm
  • Inertia Range: 4.9 to 4330 kg·cm² (series range)
  • Speed Control Accuracy: High precision with sinusoidal encoder feedback
  • Thermal Overload Capacity: Continuous high-load operation with temperature rise not exceeding 75K

Material Composition:

  • Cast iron or high-strength aluminum housing
  • Precision-laminated silicon steel rotor and stator cores
  • Copper windings with Class F insulation system
  • High-grade rolling element bearings
  • Steel output shaft with precision machining
  • Powder-coated corrosion-resistant exterior

Structural Features:

  • Robust frame construction with optimized thermal dissipation paths
  • MC mounting position configuration
  • FI-type output interface
  • Integrated PTC thermal sensors in stator winding
  • External encoder mounting adapter (/EG7S) with adapter ring
  • Forced cooling fan assembly (/V) with fan guard
  • Terminal box for power and signal connections
  • Nameplate with complete technical specifications

Working Principle:
The DRL asynchronous servo motor operates on the principle of a squirrel-cage induction motor controlled by a frequency inverter using field-oriented control (FOC) or voltage flux control (VFC). The inverter generates a rotating magnetic field in the stator, which induces currents in the rotor bars, creating electromagnetic torque. The integrated encoder provides real-time rotor position and speed feedback to the inverter, enabling precise closed-loop vector control. The forced cooling fan maintains optimal operating temperature under continuous high-load conditions.

Installation Requirements:

  • Mount on a rigid foundation with proper alignment to the driven equipment
  • Ensure the forced cooling fan has unobstructed airflow
  • Connect the encoder cable to the corresponding inverter encoder input
  • Connect PTC thermistor leads to the inverter’s thermal protection input
  • Use shielded motor cables with 360° shield grounding
  • Verify correct phase sequence (U-V-W) before startup
  • Perform motor initialization and auto-tuning via the inverter software

Usage Precautions:

  • Use exclusively with compatible SEW MOVIDRIVE or MOVIAXIS inverters for proper vector control
  • Never operate without the forced cooling fan connected when running at low speeds under heavy load
  • Monitor encoder signal integrity; loss of encoder feedback triggers immediate fault shutdown
  • Verify thermal protection circuit is correctly wired and functional before commissioning
  • Do not exceed the dynamic overload limits specified for the selected power package
  • Perform periodic bearing inspection and re-lubrication according to the maintenance schedule
  • Ensure grounding resistance is below 1 Ω
