Triconex 3301S2
Triconex 3301S2 - Image 2

Triconex 3301S2

Product Introduction: The Triconex 3301S2 is a high-integrity digital input module in the Trident safety system family, part of the Triconex SIS portfolio. It provides triple-redundant acquisition of discrete (digital) signals from field devices such as switches and contacts, with per-channel diagnostics and TMR voting. It is designed for applications requiring SIL3 safety integrity and high availability.

Request Quote
Category: SKU: Triconex 3301S2

Description

Triconex 3301S2

Technical Specifications:

  • Type: Triple-redundant digital input module (32 channels, common reference)
  • Input Voltage: Nominal 24 VDC; operating range 15–30 VDC; maximum 33 VDC
  • Input Impedance: >30 kΩ (without baseplate); ≈3 kΩ (with baseplate)
  • Response Time: <10 ms (On to Off or Off to On)
  • Diagnostics: Full per-channel diagnostics including open/short circuit detection
  • Operating Temperature: 40 °C to +70 °C
  • Humidity: 5% to 95% non-condensing
  • Mounting: Trident rack slot installation with hot-swap support
  • Certifications: SIL3 capable as part of Trident TMR architecture

Functional Features:

  • Triple-redundant input paths with 2-out-of-3 voting for each channel
  • Full on-channel diagnostics for wire-break and fault detection
  • High noise immunity via optical isolation on each channel
  • Module status LEDs and per-channel status reporting
  • Hot-swappable for online maintenance

Application Scenarios:

  • Emergency shutdown (ESD) input sensing
  • Fire and gas detector inputs
  • Valve position and limit switch feedback
  • Safety-critical discrete status monitoring in process plants

Performance Parameters:

  • Fast, deterministic response for safety-critical trips
  • High diagnostic coverage (>99%) for field wiring and channel faults

Material and Structural Characteristics:

  • Industrial PCB with optical isolation and diagnostic circuitry
  • Trident-style front panel with status indicators and keyed connector
  • Conformal coating available for harsh environments

Working Principle: Each channel is sampled by three independent circuits; results are voted within the module to eliminate single-point failures. Diagnostics continuously check for open/short conditions. Validated data is sent to main processors via the Trident I/O bus. Installation Requirements:

  • Install into a Trident I/O chassis slot; engage keyed connector
  • Connect field wiring to the associated field termination assembly (FTA); observe polarity
  • Configure input filtering and debounce via TriStation software if supported
  • Verify diagnostics during commissioning

Usage Notes:

  • Ensure field wiring does not exceed voltage ratings; use 24 VDC supplies with appropriate grounding
  • Perform regular diagnostic reviews; replace faulty modules without system shutdown (hot-swap)
  • Use shielded cables for long runs in noisy environments
