Description
Woodward 505D8200-1302
Technical Specifications
- Base Platform: Woodward 505D Digital Control.
- Part Number: 8200-1302.
- I/O Configuration: Customized analog and discrete I/O mapping.
Functional Features
- Application-Specific Logic: Pre-loaded with control strategies optimized for a specific turbine model or process requirement.
- Enhanced Integration: Customized communication protocols and Modbus mapping for seamless DCS integration.
- Standard 505D Capabilities: Retains all core speed, load, and pressure control functionalities of the base 505D platform.
Application Scenarios
Deployed in specialized power generation facilities, custom compressor packages, or as a direct replacement in legacy systems originally commissioned with the 8200-1302 configuration.
Performance Parameters
- Control Precision: Maintains the high-resolution speed and pressure control inherent to the 505D architecture.
- Response Time: Optimized PID tuning parameters specific to the 8200-1302 application.
Material Composition
Industrial-grade electronic assembly housed in a ruggedized enclosure, identical in construction to the standard 505D platform.
Structural Characteristics
- Footprint: Maintains the standard 505D physical dimensions for direct drop-in replacement.
- Identification: Clearly labeled with the 8200-1302 part number for precise inventory and maintenance tracking.
Working Principle
Operates using the same microprocessor-based control logic as the standard 505D, but executes application-specific parameters and I/O configurations loaded at the factory.
Installation Requirements
- Verification: Confirm that the 8200-1302 specifications match the existing turbine’s mechanical and electrical requirements before installation.
- Wiring: Utilize the specific wiring diagram associated with the 8200-1302 part number.
Usage Precautions
- Non-Interchangeability: Do not substitute with a generic 505D without reprogramming and verifying I/O configurations.
- Documentation: Always reference the specific manual or data sheet for the 8200-1302 variant during troubleshooting.
