Woodward 5461-647
Woodward 5461-647 - Image 2

Woodward 5461-647

Product Introduction
The Woodward 5461-647 is a regulated power supply module designed to provide stable, clean DC power to Woodward control systems. It converts incoming AC or DC line voltage to the precise DC voltages required by control modules, sensors, and actuators.

Request Quote
Category:

Description

Woodward 5461-647

Technical Specifications
  • Product Type: Regulated DC Power Supply Module.
  • Input Voltage: Wide range AC or DC input (e.g., 85-264 VAC or 100-300 VDC).
  • Output Voltage: Regulated 24 VDC, 12 VDC, or 5 VDC.
  • Output Current: Rated for the total load of the control rack.
Functional Features
  • High Efficiency: Low heat generation and energy loss.
  • Protection: Over-voltage, over-current, and short-circuit protection.
  • Redundancy Ready: Can be paralleled with diode ORing for N+1 redundancy.
  • Status Indication: LED indicates power good, overload, or fault conditions.
Application Scenarios
Used in all Woodward control panels to power the controller, I/O modules, and field instruments.
Performance Parameters
  • Ripple and Noise: Extremely low output ripple for clean power.
  • Regulation: ±1% line and load regulation.
  • Hold-Up Time: Sufficient hold-up to ride through brief power interruptions.
Material Composition
Industrial-grade switching power supply components in a metal enclosure with convection cooling
