Description
Woodward 5466-258
Technical Specifications
- Input Channels: 48 discrete inputs
- Output Channels: 24 discrete outputs
- System Compatibility: MicroNet Simplex and Redundant systems
- Chassis Compatibility: 8-slot and 14-slot Vertex-Pro chassis
- Weight: 0.86 kg
Functional Features
- High-Density I/O: Maximizes channel count in a single module slot.
- Optical Isolation: Inputs are optically isolated to protect against electrical noise and ground loops.
- Hot-Swappable: Supports real-time replacement of faulted nodes without system downtime.
- Flexible Configuration: Can be configured with high-density discrete field terminal modules (FTMs).
Application Scenarios
Deployed in petrochemical plants, power generation facilities, and motor-driven compressor applications requiring extensive discrete signal monitoring.
Performance Parameters
- Signal Response: Fast response time with excellent noise immunity.
- Reliability: Designed for continuous operation in demanding industrial environments.
Material Composition
Constructed with industrial-grade electronic components and a durable plastic housing designed for DIN rail or chassis mounting.
Structural Characteristics
- Status Indication: Features a single red LED on the front faceplate for fault diagnostics.
- Connectors: Equipped with two high-density connectors for FTM cable attachment.
Working Principle
The module reads the state of 48 external discrete devices (switches, relays) and transmits the data to the main controller. Conversely, it receives commands from the controller to energize or de-energize 24 external output devices.
Installation Requirements
Must be installed in non-hazardous areas or Class I, Division 2, Groups A, B, C, D environments. Ensure proper seating in the Vertex-Pro chassis backplane.
Precautions for Use
Verify the module address configuration before installation. Handle with ESD precautions to prevent damage to internal optical isolators.
