Description
Woodward 5501-432
Technical Specifications:
- Brand: Woodward
- Model: 5501-432
- Product Type: Digital Microprocessor Controller
- Origin: United States
Functional Features:
- Multi-Variable Control: Manages speed, load, and auxiliary functions through a single integrated controller.
- Self-Diagnostic Capabilities: Continuously monitors internal health and external system parameters to ensure high availability.
- Operator-Friendly Interface: Features a front-panel display for intuitive local monitoring and parameter adjustment.
Application Scenarios:
Ideal for power plants, industrial manufacturing facilities, and distributed energy resources utilizing turbine technology.
Performance Parameters:
- Contact Inputs: 16 (4 fixed, 12 programmable)
- Analog Inputs: 6 programmable (4-20mA)
- Analog Output: 0-10V DC
Material Composition:
Ruggedized housing with internal conformal-coated circuit boards for extended service life in harsh environments.
Structural Features:
Dimensions of approximately 15.2 cm × 5.1 cm × 20.3 cm. Includes a front-mounted operator panel with a two-line, 24-character display.
Working Principle:
Processes sensor inputs through high-precision digital algorithms to generate control outputs that precisely position turbine inlet valves.
Installation Requirements:
Requires secure mounting and proper grounding. Maintain adequate clearance around the module for heat dissipation.
Usage Precautions:
Verify all control parameters match the specific turbine application before startup. Conduct regular system health checks using the built-in diagnostics.
