Description
Woodward 8200-1301
Technical Specifications
- Brand: Woodward
- Part Number: 8200-1301
- Product Type: Digital Governor
- Series: 8200 Digital Governors
Functional Features
- Digital Precision: Superior control resolution compared to analog governors.
- Comprehensive Protection: Monitors overspeed, underspeed, and other critical parameters.
- Flexible Configuration: User-programmable parameters via front panel or software.
Application Scenarios
Deployed in diesel generator sets, gas engines, and mechanical drive turbines.
Performance Parameters
- Response Time: Fast digital processing for excellent transient response.
- Accuracy: Tight speed regulation under varying load conditions.
Material Composition
High-reliability microprocessors and conformal-coated PCBs.
Structural Characteristics
Rugged enclosure with front-panel interface, status LEDs, and rear field wiring connectors.
Working Principle
Digitizes speed sensor signals, executes governing algorithms, and outputs precise actuator commands to maintain set speed or load.
Installation Requirements
Mount in a clean, dry control panel. Follow wiring diagrams strictly for sensor connections.
Usage Precautions
Backup configuration before making changes. Only qualified personnel should adjust protection setpoints.
