Description
Woodward 8273-1011
Technical Specifications
- Control Voltage: 24V DC input.
- Communication Interface: RS-232 port for configuration via PC software.
- Control Modes: Isochronous, Droop, and Base Load.
- Chassis Compatibility: Designed for MicroNet Simplex or MicroNet Plus chassis.
Functional Features
- Load Sharing: Seamlessly distributes electrical load among multiple generators operating in parallel.
- Speed Regulation: Maintains constant engine frequency regardless of load fluctuations.
- Soft Loading: Allows for smooth addition or removal of generators from the bus without power surges.
- Engine Protection: Monitors critical parameters and triggers alarms or shutdowns to prevent catastrophic damage.
Application Scenarios
Widely deployed in power generation plants, marine propulsion systems, and industrial facilities requiring stable backup power or cogeneration.
Performance Parameters
- Response Time: Fast digital processing ensures immediate reaction to sudden load changes.
- Accuracy: High-precision speed and load matching for optimal generator efficiency.
Material Composition
Constructed with industrial-grade printed circuit boards (PCBs) and housed in a rugged metal chassis designed to withstand harsh industrial environments.
Structural Characteristics
Features a front panel with four diagnostic LED indicators (OK, Input Fault, Power Fault, Over-Temperature) and a 9-pin RS-232 configuration port.
Working Principle
The controller continuously monitors engine speed and generator load. Using advanced PID algorithms, it calculates the required fuel adjustment and sends precise signals to the engine actuator to maintain the target setpoints.
Installation Requirements
Must be securely mounted in a compatible MicroNet chassis. Wiring must utilize 14 AWG or 2.5 mm² conductors rated for at least 60°C.
Usage Precautions
Always observe strict Electrostatic Discharge (ESD) protocols when handling the PCB. Never remove the module while the system is energized.
