Product Introduction
The EASYGEN-3100-5 is an advanced digital microprocessor controller module engineered for the comprehensive control and monitoring of industrial turbine generators. It integrates engine control, generator protection, and automatic synchronization into a single, highly reliable platform.

Request Quote
Category:

Description

Woodward EASYGEN-3100-5

Technical Specifications

  • Input Configuration: 16 discrete inputs (4 fixed, 12 programmable) and 6 programmable 4-20mA analog inputs.
  • Output Signals: 0-10V DC analog outputs for actuator and valve driving.
  • Communication: RS-232 and Ethernet interfaces supporting Modbus protocols.
  • Display: Two-line text display (24 characters per line).

Functional Features

  • Speed & Load Control: Regulates turbine speed and load via single extraction and/or intake steam valves.
  • Advanced Synchronization: Supports isochronous load sharing and seamless grid synchronization.
  • Real-Time Diagnostics: Continuous self-diagnostics and performance monitoring (speed, temperature, pressure).
  • Complex Logic Execution: Utilizes high-precision algorithms for critical speed avoidance and valve limiting.

Application Scenarios
Ideal for steam turbines, gas turbines, and turbo-generators requiring precise speed regulation, load control, and grid-parallel operation.

Performance Parameters

  • Control Accuracy: High-precision digital PID control for stable frequency and voltage regulation.
  • Response Time: Fast dynamic response to sudden load changes and grid disturbances.

Material Composition
Housed in a compact sheet metal enclosure providing excellent electromagnetic shielding and physical protection.

Structural Characteristics

  • Dimensions: 15.2 cm x 5.1 cm x 20.3 cm.
  • Weight: Approximately 0.7 kg.
  • Modularity: Compact design facilitates easy panel integration.

Working Principle
Acquires real-time electrical and mechanical signals, processes them through embedded control algorithms, and outputs precise analog or discrete signals to prime mover actuators and generator breakers.

Installation Requirements
Install in a clean, dry control panel. Ensure communication cables are properly shielded and terminated to maintain network integrity.

Precautions for Use
Verify all input/output configurations match the physical wiring before commissioning. Utilize the ToolKit software for advanced parameter tuning and trending.
