Description
Woodward PCU-1000
Technical Specifications
- Processor: High-speed industrial microprocessor.
- I/O Capacity: Extensive digital and analog I/O.
- Communication: Multiple serial and Ethernet ports.
- Programming: Ladder logic, function block, or proprietary software.
Functional Features
- Advanced Control: PID, cascade, ratio, and batch control.
- Data Logging: Trending and event recording capabilities.
- Redundancy: Optional power and communication redundancy.
- HMI Integration: Seamless connection to operator displays.
Application Scenarios
Used in compressor stations, boiler control, marine propulsion, and custom OEM machinery.
Performance Parameters
- Scan Time: Millisecond-level execution for critical loops.
- Memory: Large memory for complex programs and data logging.
Material Composition
Industrial-grade enclosure with conformal-coated PCBs.
Structural Characteristics
- Modular: Expandable I/O modules.
- Display: Optional local display or keypad.
Working Principle
Reads I/O inputs, executes the user-programmed logic at high speed, and updates outputs to control the process or machinery.
Installation Requirements
Provide adequate ventilation. Use shielded cables for analog I/O and communication.
Precautions for Use
Secure the control program with passwords. Perform regular backups of the configuration.
