Description
Woodward UG-10D705-1481RPM
Technical Specifications
- Base Model: UG-10D
- Part Number: 705-1481RPM
- Rated Speed: 1481 RPM
Functional Features
- Speed-Specific Calibration: Optimized for stable operation at exactly 1481 RPM.
- Precise Regulation: Maintains exact speed setpoint with minimal deviation.
- Reliable Performance: Proven UG-10D mechanical-hydraulic reliability.
Application Scenarios
Deployed in specialized mechanical drives, marine applications, or generator sets requiring exact 1481 RPM operation.
Performance Parameters
- Rated Speed: 1481 RPM (exact calibration).
- Speed Regulation: Tight tolerance around 1481 RPM setpoint.
Material Composition
Industrial-grade components with precision-calibrated speed springs and flyweight assemblies.
Structural Characteristics
- Custom Calibration: Internal speed setting mechanism calibrated for 1481 RPM.
- Standard UG-10D Form Factor: Compatible with standard mounting and linkage interfaces.
Working Principle
Mechanical flyweights are calibrated to achieve equilibrium at exactly 1481 RPM. Speed deviations cause flyweight movement that actuates the hydraulic servo to restore the precise 1481 RPM setpoint.
Installation Requirements
Verify the 1481 RPM rating matches the application requirements. Ensure proper linkage alignment and oil level before operation.
Precautions for Use
Do not attempt to adjust the speed setting significantly beyond the calibrated 1481 RPM range. Regular maintenance of oil and linkages is essential for maintaining precise speed control.
