Description
Woodward VM2104.0000
Technical Specifications:
- Brand: Woodward
- Model: VM2104.0000
- Product Type: Industrial Control Component
Functional Features:
- Precise Signal Conversion: Achieves accurate conversion and isolation of various industrial standard signals (e.g., 4-20mA, 0-10V, thermocouples).
- High Reliability: Fully sealed potting or conformal coating processes prevent dust and moisture intrusion.
Application Scenarios:
Extensively used in temperature, pressure, and flow monitoring and control loops in power plants, petrochemical facilities, and marine propulsion.
Performance Parameters:
- Conversion Accuracy: Extremely high linearity and minimal zero drift.
- Response Time: Fast signal update rate to meet high-speed control loop requirements.
Material Composition:
High-strength engineering plastic or die-cast aluminum housing with multi-layer immersion gold internal PCBs.
Structural Characteristics:
DIN rail or panel cutout mounting with spring-clamp or anti-loosening screw terminals.
Working Principle:
Utilizes precision operational amplifiers and A/D, D/A converters to isolate, amplify, and linearly compensate input signals, outputting standardized control signals.
Installation Requirements:
Avoid installation near strong magnetic fields or high-temperature heat sources. Use twisted-pair shielded cables for signals, routed separately from power lines.
Usage Precautions:
Confirm signal type matching before wiring. Regularly calibrate accuracy using high-precision calibrators.
