Description
Foxboro P0916KF
Technical Specifications
- Model: P0916KF.
- Architecture: 32-bit RISC.
- Memory: 8 MB Program / 4 MB Data.
- Interfaces: 100 Mbps Fiber Ethernet, RS-232.
Functional Features
- Bit-by-Bit Matching: Utilizes unique redundancy technology to verify data consistency between primary and backup processors.
- High-Density I/O: Supports extensive I/O expansion for large-scale process units.
- Real-Time Data Acquisition: Continuously collects temperature, pressure, and flow variables with alarm detection.
Application Scenarios
Deployed in refining, chemical processing, and utility sectors for continuous process control and safety-critical monitoring.
Performance Parameters
- Power Consumption: 10 W typical.
- Dimensions: 140 mm x 165 mm x 45 mm.
- Weight: 0.6 kg.
Material Composition
High-grade die-cast aluminum chassis. Internal PCBs use multi-layer FR4 material with high-Tg ratings for thermal stability.
Structural Characteristics
Features a distinct label with the P0916KF part number. Includes integrated fiber optic transceiver ports and fieldbus termination options.
Working Principle
Acts as the master node on the local fieldbus segment, polling slave FBMs, executing PID and logic blocks, and synchronizing with the redundant peer via a high-speed backplane or fiber link.
Installation Requirements
Mount vertically or horizontally as per mechanical drawings. Ensure 100 Mbps fiber links are connected to the correct TX/RX ports on the Ethernet switch.
Usage Precautions
Store in anti-static packaging when not installed. Do not apply power if the module shows physical damage or moisture ingress.
