Description
ABB 07KT92 CS31
Technical Specifications:
- Brand: ABB
- Model Number: 07KT92 CS31
- Product Type: Bus Terminal / End-of-Line Module
- Protocol: CS31 Fieldbus
Functional Features:
- Signal Termination: Prevents signal reflections that can cause communication errors and data loss.
- Network Stability: Maintains the electrical characteristics of the bus within specified limits.
- Easy Identification: Visual indicators or mechanical keys to denote end-of-line status.
Application Scenarios:
- Installed at the physical end of a CS31 fieldbus network.
- Used in distributed I/O and sensor networks across large industrial facilities.
Performance Parameters:
- Signal Integrity: Ensures clean, noise-free communication across the entire bus segment.
- Reliability: Passive, solid-state design with no moving parts for maximum uptime.
Material Composition & Structural Features:
- Compact Housing: Space-saving design for dense control panels.
- Secure Connectors: Reliable terminal blocks or plug-in connectors for field wiring.
Working Principle:
Provides the precise electrical impedance required at the end of a transmission line to absorb the signal energy, preventing it from bouncing back and interfering with valid data packets.
Installation Requirements:
- Must be installed strictly at the physical end of the bus cable.
- Ensure the termination resistor or circuit is properly engaged.
Usage Precautions:
- Never remove the terminal module while the bus is active, as it will cause immediate network failure.
- Verify bus health using diagnostic tools after installation.
