Description
ABB 2GUS031803A9
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 2GUS031803A9 |
| Brand | ABB |
| Type | Protection Relay / Process Control Module |
| Operating Voltage | 220V AC |
| Input Range | -10% to +10% of full scale |
| Process Current | 4-20mA |
| Communication Protocol | MODBUS RTU |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Protection Class | IP65 |
| Dimensions | 154mm × 114mm × 92mm |
| Weight | 0.5 kg |
Function Features
- Comprehensive Protection: Provides overcurrent, short-circuit, and earth fault protection for electrical networks
- Advanced Control: Enables remote or automated control of circuit breakers
- Real-Time Monitoring: Monitors voltage, current, and power quality parameters continuously
- Adaptive Control: Advanced algorithms dynamically adjust to changing process conditions
- Modular Architecture: Easy integration into existing control systems with minimal downtime
- Diagnostic Capabilities: Proactive monitoring and troubleshooting for continuous operation
- High-Grade Materials: Withstands harsh environmental conditions for longevity and durability
Application Scenarios
- Industrial power distribution and motor protection
- Oil and gas process control
- Chemical processing plants
- Food and beverage industry
- Renewable energy systems (solar/wind substations)
- Data centers and critical infrastructure
- Smart grid and SCADA integration
Working Principle
The protection relay continuously monitors electrical parameters through current and voltage transformers. When abnormal conditions are detected (overcurrent, short-circuit, earth fault), the relay calculates the fault characteristics and triggers appropriate protective actions, such as tripping circuit breakers. The modular control functions enable process optimization through feedback loops and adaptive algorithms.
Material and Structure
- High-grade industrial components
- Robust housing with IP65 protection
- Compact modular design for switchgear panel installation
- LED indicators for status and diagnostics
Installation Requirements
- Install in switchgear panels or control cabinets
- Connect to ABB Tmax XT or Emax 2 circuit breakers
- Use professional installation and configuration via ABB Ability or Relion Toolkit software
- Ensure proper CT and VT connections for accurate measurement
Usage Notes
- Configure protection settings according to system requirements
- Perform regular testing of protection functions
- Update firmware through ABB proprietary software
- Verify communication settings for SCADA integration
- Follow international safety standards (IEC/EN 60947, IEC 60255)
