ABB 3BHB045828R0001
Technical Specifications:
| Parameter | Value |
|---|---|
| Product Model | 3BHB045828R0001 |
| Manufacturer | ABB |
| Product Category | Control Module / I/O Module / Analog Output Board |
| Origin | USA |
| Working Voltage | Bus voltage: 24 V; Power supply voltage: DC 24 V (±10%) |
| Rated Current | 2 A maximum load capacity |
| Monitoring Current | Bus current ≤1 mA; Power supply current ≤5 mA |
| Operating Current | Bus current ≤3 mA; Power supply current ≤20 mA |
| Digital Input | 16 channels, supporting 24 V DC / 110 V AC signals |
| Analog Output | 4 channels, 0–10 V / 4–20 mA configurable (accuracy ±0.1%) |
| Response Time | ≤1 ms |
| Communication Protocols | Profibus DP, Modbus RTU, Ethernet TCP/IP |
| Dimensions | 120 mm × 80 mm × 40 mm |
| Weight | Approximately 0.5 kg |
| Protection Rating | IP65 (dust and water resistant) |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Vibration Resistance | 5 G vibration, 50 G shock (per IEC 60068-2) |
| Mounting | DIN rail (EN 60715 standard) |
| Housing Material | Flame-retardant PC + metal housing (UL94 V-0 certified) |
| Certifications | CE, UL, RoHS; compliant with IEC 61131, EN 50178 |
Functional Features:
- Multi-Channel I/O: 16 digital input channels and 4 analog output channels for comprehensive signal handling.
- High-Speed Processing: ≤1 ms response time for real-time control applications.
- Flexible Output Control: Supports pulse and level output modes with relay normally open contact output or active output configurations.
- Wide Voltage Compatibility: Passive output contact capacity supports DC24V/2A, suitable for 12 V to 48 V DC or AC applications.
- Robust Communication: Multi-protocol support enables seamless integration with ABB AC500, AC800M series PLCs, and third-party control systems.
- Advanced Environmental Protection: IP65 rating ensures reliable operation in high-humidity and dusty industrial environments.
Application Scenarios:
- Factory automation and process control systems
- Building automation and HVAC control
- Water treatment and wastewater management
- Material handling and conveyor systems
- Energy management and power distribution
Material and Structure:
- Flame-retardant polycarbonate and metal composite housing
- Compact DIN rail-mountable design for space-efficient cabinet installation
- High-density industrial-grade terminals for secure connections
Installation Requirements:
- Non-polar two-bus connection for both signal and power supply
- Ensure proper grounding and shielding for electromagnetic compatibility
- Install in environments with adequate ventilation for heat dissipation
