Description
ABB 3BHE009017R0102 XVC724BE102
Technical Specifications:
| Parameter | Value |
|---|---|
| Product Model | XVC724BE102 / 3BHE009017R0102 |
| Manufacturer | ABB |
| Product Category | VLSCD Board / Network Communication Module / Processor Module |
| Series | Advant 800XA / ACS2000 / Symphony Plus DCS |
| Rated Voltage | 380–480 VAC (VLSCD); 24 V DC (communication) |
| Rated Current | 1000 A (VLSCD); 2 A (control) |
| Input Voltage Range | 12–48 V DC (processor); 24 V DC to 550 V DC (VLSCD) |
| Output Voltage | 5 V DC |
| Output Current | Maximum 10 A |
| Efficiency | >90% |
| Response Time | <10 µs (short circuit detection) |
| Dimensions | 110 mm × 80 mm × 40 mm (VLSCD); 170 mm × 105 mm × 32 mm (processor) |
| Weight | 0.5 kg to 1.0 kg |
| Protection Rating | IP20 |
| Operating Temperature | -25°C to +85°C (VLSCD); 0°C to +60°C (communication) |
| Storage Temperature | -40°C to +90°C (VLSCD); -40°C to +85°C (communication) |
| Humidity | 95% RH non-condensing |
| Vibration | 0.5 g (20–500 Hz) |
| Shock | 15 g (11 ms) |
| Insulation Resistance | ≥100 MΩ |
| Dielectric Strength | 2.5 kV AC |
| Mechanical Life | 10,000 operations |
| Electrical Life | 10,000 operations |
| Communication Protocols | INFI-NET, Ethernet, Modbus TCP, Profibus DP |
| CPU | 32-bit RISC processor |
| I/O Channels | 16 configurable digital/analog channels |
Functional Features:
- Short Circuit Protection: VLSCD technology detects drive output voltage short circuits with <10 µs response time, protecting inverter and motor systems.
- Network Management: Functions as network manager or backup manager for INFI-NET, handling token passing, error diagnosis, node status monitoring, and network reconfiguration.
- Redundant Communication: Provides redundant INFI-NET ports for connection to plant control loops and unit loops.
- High-Speed Processing: 32-bit RISC processor handles large volumes of broadcast, peer-to-peer, and client/server communication requests.
- Multi-Protocol Support: Ethernet/IP, Modbus TCP, and Profibus DP for seamless PLC, HMI, and DCS integration.
- Hot-Swappable Design: Supports带电插拔 (hot insertion/removal) for maintenance without system shutdown.
- Advanced Control Functions: Integrates voltage regulator with PID filter, excitation current regulator with PI filter, reactive/active current droop compensation, limiter circuits, and power system stabilizers.
Application Scenarios:
- Drives and Inverters: Motor speed and torque control; DC-to-AC and AC-to-DC power conversion.
- Power Supplies: Voltage and current regulation.
- Oil and Gas: Valve positioning and flow rate management in pipelines.
- Power Generation: Grid stability monitoring through turbine speed and load distribution regulation.
- Industrial Automation: Manufacturing, chemical industry, and process control systems.
Material and Structure:
- Metal and plastic composite construction
- Coated board for protection against harsh environments
- Compact design for easy installation and maintenance
Working Principle: As a VLSCD board, it continuously monitors drive output voltage levels and instantly triggers protection circuits when short circuit conditions are detected. As a communication module, it processes and routes control data across redundant network architectures, ensuring deterministic data delivery.
