Product Brief:​ The CP676 is the large-format member of ABB CP600 HMI family, featuring a 15-inch XGA TFT display suitable for dense process graphics, multi-loop overview, or large machine interfaces. It runs PB610 runtime, supports the same communication drivers as CP650/CP651-WEB, and is panel-mounted.

Request Quote
Category: SKU: ABB CP676

Description

ABB CP676

  • Technical Specifications:
    • Display: 15.0″ TFT-LCD, 1024 × 768 (XGA), 65 K colors
    • Touch: 4-wire resistive single-touch
    • Processor: ARM Cortex-A8 1 GHz (or equivalent RISC)
    • Memory: 256 MB RAM, 256–512 MB Flash (project dependent)
    • Interfaces: 2 × 10/100 Mbps Ethernet, 1 × RS-232/485, 2 × USB, SD slot
    • Power: 24 V DC (18–30 V DC), typical 18 W max
    • Brightness: 300–350 cd/m², LED backlight
    • Front: IP65; Rear: IP20
    • Operating Temp.: –25 °C to +60/70 °C (model variant)
    • Cutout: ≈361 × 274 mm; depth ≈60 mm
    • Weight: ≈3.2 kg
  • Functional Features:
    • Large canvas for P&ID-style plant overviews, multi-tag alarm lists, historical trends
    • Same PB610 feature set — recipes, scheduler, multi-language, scripts
    • Multiple driver sessions concurrently (e.g., ABB AC500 + Modbus TCP + S7 driver)
    • VNC server for remote desktop-style view
  • Application Scenarios:
    • Process plant local operator station (oil & gas, pharma, chemical)
    • Large packaging/filling line main control console
    • Power substation HMI for bay-level monitoring
    • Batch process control room panel
  • Material & Structure / Working Principle / Installation / Precautions:​ Consistent with CP600 series — note:
    • Installation:​ Requires larger cutout and adequate rear clearance (≥70 mm recommended)
    • Power:​ Verify 24 V DC supply has sufficient current (≥1 A @ 24 V DC)
    • Cleaning:​ Use lint-free cloth; do not press hard on screen — larger screens are more sensitive to point-load damage
