Description
ABB TA524
Technical Specifications:
- Weight: 50 g.
- Dimensions: 135 mm (Height) x 28 mm (Width) x 62 mm (Depth).
- Order Code: 1SAP 180 600 R0001.
- Product Life Cycle Phase: Active.
Functional Features:
- Dust Protection: Effectively prevents dust, debris, and moisture from entering the terminal base through empty slots.
- Safety Barrier: Protects maintenance personnel from inadvertent contact with live internal electrical components.
- Seamless Integration: Mounted using the exact same mechanical procedure as a standard communication module.
Application Scenarios:
Deployed in any AC500 PLC installation where the terminal base features more communication slots than are actively utilized by the system architecture.
Performance Parameters:
- Mechanical Durability: Engineered for repeated insertion and extraction without degrading the terminal base connectors.
- Environmental Sealing: Provides a tight physical fit to maintain the IP rating of the control cabinet.
Material Composition:
Constructed from high-quality, flame-retardant industrial-grade plastic designed to withstand harsh factory environments.
Structural Features:
Features a standardized mechanical footprint identical to active communication modules, complete with a dedicated label area for panel documentation.
Working Principle:
Operates as a purely passive mechanical component. It physically occupies the slot to block environmental contaminants and prevents accidental electrical contact without requiring any power or data connections.
Installation Requirements:
Align the module with the terminal base guides and press firmly until it seats securely. Follow standard mounting and demounting instructions for AC500 communication modules.
Usage Precautions:
Always install a TA524 in any unused slot to maintain system safety and environmental protection. Do not attempt to modify or drill into the dummy module.
