Description
ABB TU810V1 3BSE013230R1
Technical Specifications:
- Order Code: 3BSE013230R1.
- Module Compatibility: S800 digital and analog I/O modules.
- Terminal Type: Spring-clamp terminals for fast, tool-free wiring.
- Field Voltage: Supports 24V DC field power distribution.
Functional Features:
- Hot-Swap Support: Enables module replacement without system shutdown.
- Shield Grounding: Dedicated shield connection point for EMI protection.
- Clear Labeling: Integrated labeling area for wire identification.
- Test Points: Accessible test points for field signal verification.
Application Scenarios:
- Distributed I/O in power generation and distribution.
- Process automation in oil and gas facilities.
- Manufacturing and packaging line control.
Material Composition & Structural Characteristics:
- Enclosure: Compact, flame-retardant plastic housing.
- Mounting: Standard DIN rail mountable.
- Connectors: Precision socket for S800 module connection.
Working Principle:
Field wires are terminated on the TU810V1 base unit. When an S800 I/O module is plugged in, it mates with the base unit’s internal contacts, establishing electrical connections for power, signals, and diagnostics. The base unit routes these connections to the module’s internal circuitry.
Installation Requirements:
- Mount securely on a DIN rail.
- Use appropriate ferrules for stranded wire connections.
- Ensure the shield clamp makes good contact with the cable shield.
Usage Precautions:
- Verify the base unit variant matches the I/O module requirements.
- Do not force the module onto the base unit; ensure proper alignment.
