ABB UBC717BE101 3BHE021887R0101

ABB UBC717BE101 3BHE021887R0101

Product Introduction:
The ABB UBC717BE101, identified by the material number 3BHE021887R0101, is a high-performance main control board and digital I/O module. It serves as the core processing unit within industrial automation systems, specifically designed for integration with ABB ACS 800 series high-voltage variable frequency drives and Distributed Control Systems (DCS). It acts as the intelligent brain of the drive system, managing complex control algorithms, signal processing, and command execution.

Request Quote
Category:

Description

ABB UBC717BE101 3BHE021887R0101

Technical Specifications:

  • Operating Voltage: 24 VDC power supply.
  • Operating Temperature Range: -30°C to +70°C.
  • Environmental Humidity: 5% to 95% non-condensing.
  • Communication Protocols: PROFIBUS DP, Modbus TCP/RTU, EtherNet/IP, CANopen, and ABB DrivesLink.
  • I/O Capacity: Supports up to 16 analog inputs, 8 analog outputs, 32 digital inputs, and 32 digital outputs.
  • Storage Capacity: 512MB RAM and 1GB Flash memory.
  • Dimensions: Approximately 20cm x 15cm x 8cm.
  • Mean Time Between Failures (MTBF): 200,000 hours.

Functional Features:

  • High-Speed Processing: Executes advanced control algorithms like Direct Torque Control (DTC) with millisecond-level response times.
  • Multi-Protocol Adaptability: Functions as a communication gateway, seamlessly converting fieldbus signals to Ethernet formats for integration with DCS systems (e.g., ABB AC 800M, Siemens PCS7).
  • Edge Computing & Preprocessing: Supports OPC UA protocol for cloud integration, featuring built-in hardware acceleration for data filtering and aggregation.
  • Redundant Communication: Equipped with dual Gigabit Ethernet ports supporting hot standby switching for continuous network availability.
  • Integrated Diagnostics: Features non-volatile EEPROM for parameter storage and built-in indicators for power, communication, and I/O faults.

Application Scenarios:

  • Power Generation: Controls induction and forced draft fans (1500kW-3000kW) in thermal power plants, adjusting air volume based on boiler load.
  • Metallurgy: Regulates rolling mill drives to ensure uniform steel plate thickness by rapidly processing pressure sensor signals.
  • Chemical Processing: Manages centrifugal compressors in highly electromagnetic-interfered environments, preventing parameter loss and false tripping.
  • System Upgrades: Serves as a direct replacement for aging control boards in legacy ACS 800 drives, extending equipment lifespan without full system replacement.

Performance Parameters:

  • Data Transmission Delay: Less than 10ms for high-speed control scenarios.
  • Frequency Response Adjustment Time: ≤100ms for dynamic load changes.
  • Protection Level: IP20.
  • Electromagnetic Compatibility (EMC): Robust design resisting RFI and EFT interference in high-voltage environments.

Material Composition:
Manufactured with industrial-grade electronic components, featuring a durable metal and high-quality plastic housing designed to withstand severe operational conditions.

Structural Features:
Features a modular design with standard DIN rail installation support. It includes dual Gigabit Ethernet ports (RJ45), RS485/RS232 serial interfaces, and Profibus DP connections.

Working Principle:
The module continuously monitors field sensors and receives setpoint commands via industrial networks. Its high-speed processor calculates the required motor torque and speed, outputting precise Pulse Width Modulation (PWM) signals to the drive’s power unit. It simultaneously handles bidirectional communication with the master DCS and performs real-time self-diagnostics.

Installation Requirements:

  • Install in a climate-controlled control cabinet with adequate ventilation.
  • Ensure firmware version is V4.5 or above for compatibility.
  • Always back up parameters from the old board using ABB DriveCom software before installation.

Usage Precautions:

  • Strictly verify compatibility; this board is exclusively for ACS 800 series drives and is not compatible with ACS 580 or ACS 600 models.
  • Handle with Electrostatic Discharge (ESD) protection.
  • Never install refurbished boards with degraded EEPROM, as this leads to parameter loss and potential power unit damage.
