Product Brief Introduction: 30103‑00‑04‑10‑02‑00 belongs to Bently Nevada 3300 XL 8 mm high‑performance eddy‑current proximity probe system, widely used for non‑contact measurement of rotating‑shaft radial vibration, shaft‑thrust‑axial‑position,‑shaft‑expansion‑value‑and‑rotor‑key‑phasor‑signal‑acquisition‑on‑critical‑rotating‑machinery‑such‑as‑steam‑turbines‑and‑centrifugal‑compressors.

Request Quote
Category:

Description

Bently 30103‑00‑04‑10‑02‑00

  • Technical Specifications
    • Sensing‑Principle: High‑frequency‑eddy‑current‑inductive‑non‑contact‑measurement
    • Nominal‑System‑Sensitivity: 7.87 mV/μm (200 mV/mil)
    • Nominal‑Linear‑Measurement‑Range: 2.0 mm (80 mils)
    • Probe‑Integrated‑Cable‑Length: 0.4 meter
    • Probe‑Mount‑Thread‑Specification: 3/8‑24 UNF‑thread
    • Cable‑Armour‑Configuration: Without‑metal‑armored‑jacket
    • Frequency‑Response‑Range: 0 Hz‑10 kHz (±3 dB)
    • Probe‑Body‑Operating‑Temperature‑Range:‑51 °C ~ +177 °C
    • Probe‑Body‑Storage‑Temperature‑Range:‑51 °C ~ +204 °C
    • Maximum‑Allowable‑Differential‑Pressure: Probe‑tip‑seal‑supports‑differential‑pressure‑with‑Viton‑O‑ring‑sealing‑element
    • Target‑Measured‑Material: Conductive‑metallic‑shaft‑surface;‑material‑factor‑correction‑required‑for‑non‑standard‑steel‑target
    • Connector‑Type: 3300‑XL‑standard‑triax‑connector
  • Functional Features: Patented‑TipLoc‑molding‑process‑ensures‑reliable‑bond‑strength‑between‑probe‑tip‑ceramic‑component‑and‑probe‑metal‑body,‑improving‑anti‑vibration‑and‑anti‑thermal‑shock‑performance.‑Full‑component‑interchangeability‑of‑3300‑XL‑system:‑probe,‑extension‑cable‑and‑Proximitor‑sensor‑can‑be‑replaced‑on‑site‑without‑additional‑matching‑calibration‑procedure.‑Wide‑operating‑temperature‑range‑adapts‑to‑high‑temperature‑environment‑of‑machinery‑bearing‑cavity.‑Probe‑can‑work‑normally‑when‑surrounded‑by‑oil‑mist,‑lubricating‑oil‑and‑steam‑vapour‑non‑conductive‑medium.‑Provides‑static‑gap‑DC‑voltage‑output‑and‑dynamic‑vibration‑AC‑signal‑output‑simultaneously,‑supporting‑both‑protection‑interlock‑and‑machinery‑fault‑diagnosis‑application.‑Compatible‑with‑3300‑series‑Proximitor‑sensor,‑3500‑monitor‑rack‑system‑and‑1900‑series‑general‑purpose‑monitor‑modules.‑When‑matched‑with‑corresponding‑certified‑Proximitor‑sensor,‑this‑probe‑assembly‑can‑be‑used‑in‑hazardous‑classified‑industrial‑zones.‑This‑variant‑does‑not‑have‑metal‑armored‑cable‑jacket,‑so‑external‑metal‑conduit‑protection‑is‑required‑for‑field‑cable‑routing‑installation.
  • Application Scenarios: Non‑contact‑radial‑shaft‑vibration‑monitoring‑for‑steam‑turbines,‑centrifugal‑compressors,‑turbo‑generators‑and‑large‑process‑pumps.‑Thrust‑bearing‑axial‑position‑measurement‑and‑shaft‑thermal‑expansion‑monitoring‑for‑fluid‑film‑bearing‑rotating‑machinery.‑Keyphasor‑rotational‑speed‑and‑phase‑reference‑signal‑acquisition‑for‑rotor‑dynamic‑analysis.‑Widely‑applied‑in‑power‑generation‑plants,‑refineries‑and‑petrochemical‑complex‑critical‑machinery‑protection‑systems‑complying‑with‑API‑670‑standard.
  • Performance Parameters: System‑linearity‑error‑within‑linear‑range‑is‑less‑than‑±0.025 mm.‑Thermal‑sensitivity‑drift‑under‑full‑operating‑temperature‑range‑keeps‑within‑±0.5 %‑full‑scale.‑Good‑electromagnetic‑interference‑rejection‑performance‑against‑60‑Hz‑industrial‑magnetic‑field‑disturbance.‑Probe‑internal‑coil‑adopts‑high‑stability‑winding‑process‑to‑reduce‑long‑term‑aging‑drift.‑Signal‑output‑quality‑will‑not‑be‑influenced‑by‑non‑conductive‑oil‑mist‑and‑steam‑surrounding‑probe‑tip.‑Measurement‑accuracy‑will‑be‑affected‑if‑target‑surface‑has‑non‑conductive‑coating,‑rust‑or‑surface‑deformation.
  • Material Composition: Probe‑tip‑is‑high‑purity‑ceramic‑insulation‑material‑with‑precision‑wound‑internal‑sensing‑coil.‑Probe‑main‑body‑is‑stainless‑steel‑machined‑component.‑Internal‑sealing‑element‑is‑Viton‑fluororubber‑O‑ring.‑Probe‑integrated‑cable‑adopts‑triaxial‑shielded‑cable‑structure,‑outer‑jacket‑is‑oil‑resistant‑polyurethane‑material,‑without‑metal‑armor‑layer.‑Connector‑contact‑pieces‑are‑gold‑plated‑beryllium‑copper‑alloy‑to‑prevent‑contact‑oxidation.
  • Structural Characteristics: Cylindrical‑probe‑body‑with‑3/8‑24‑UNF‑external‑mount‑thread‑on‑probe‑rear‑section.‑Front‑end‑ceramic‑probe‑tip‑houses‑internal‑sensing‑coil‑assembly.‑Integrated‑triax‑shielded‑cable‑extends‑from‑probe‑rear‑end.‑Probe‑rear‑end‑equipped‑with‑standard‑3300‑XL‑triax‑connector‑for‑connecting‑extension‑cable.‑Hermetic‑sealing‑structure‑between‑probe‑ceramic‑tip‑and‑metal‑body‑resists‑penetration‑of‑oil‑and‑moisture‑into‑probe‑internal‑cavity.
